  • Highline

    ×

    8 730 155 119

    Highline

    Housing colour

    silver grey
    black
    white

    Fixation

    with mounting flange
    with wall bracket
    with wall arm

    Colour temperature

    4000 K
    3000 K

    Light distribution

    Control

    on / off
    DALI
    1-10V
    Specification
    Colour
    silver grey
    Fixation
    with wall bracket
    Light distribution
    narrow beam
    Beam angle (FWHM)
    6°
    Light source
    LED 4000 K
    Luminous flux
    1561 lm
    Power
    23 W
    Efficiency
    69 lm/W
    Control
    DALI
    Color Rendering Index cri
    CRI > 80 > 80
    Colour tolerance
    max 2 SDCM
    Service life
    L: 90, B:10
    Download

    Highline is a range of façade luminaires of minimalistic design. They are available with wall washer, narrow beam or asymmetrical distribution. The fields of application range from accent lighting to uniform wall washing. Highline is a versatile instrument for many different applications, in a uniform and discreet housing.

    Preselection
    Light source
    Fixation
    Colour
    Light distribution
    Colour temperature
    Control

    126 Products
    •   Part number Description Colour Light distribution Light source Luminous flux Power
    • 8 730 055 0098 730 055 009Highlinesilver greywall washer 14° / 93°LED 4000 K1345 lm23 Won / off
    • 8 730 055 0198 730 055 019Highlinesilver greynarrow beam 6°LED 4000 K1561 lm23 Won / off
    • 8 730 055 0898 730 055 089Highlinesilver greyasymmetrical 35° / 30°LED 4000 K1177 lm22 Won / off
    • 8 730 055 1098 730 055 109Highlinesilver greywall washer 14° / 93°LED 4000 K1345 lm23 WDALI
    • 8 730 055 1198 730 055 119Highlinesilver greynarrow beam 6°LED 4000 K1561 lm23 WDALI
    • 8 730 055 1898 730 055 189Highlinesilver greyasymmetrical 35° / 30°LED 4000 K1177 lm22 WDALI
    • 8 730 055 2098 730 055 209Highlinesilver greywall washer 14° / 93°LED 4000 K1345 lm23 W1-10V
    • 8 730 055 2198 730 055 219Highlinesilver greynarrow beam 6°LED 4000 K1561 lm23 W1-10V
    • 8 730 055 2898 730 055 289Highlinesilver greyasymmetrical 35° / 30°LED 4000 K1177 lm22 W1-10V
    • 8 730 056 0098 730 056 009Highlinesilver greywall washer 14° / 93°LED 3000 K1281 lm23 Won / off
    • 8 730 056 0198 730 056 019Highlinesilver greynarrow beam 6°LED 3000 K1487 lm23 Won / off
    • 8 730 056 0898 730 056 089Highlinesilver greyasymmetrical 35° / 30°LED 3000 K1121 lm22 Won / off
    • 8 730 056 1098 730 056 109Highlinesilver greywall washer 14° / 93°LED 3000 K1281 lm23 WDALI
    • 8 730 056 1198 730 056 119Highlinesilver greynarrow beam 6°LED 3000 K1487 lm23 WDALI
    • 8 730 056 1898 730 056 189Highlinesilver greyasymmetrical 35° / 30°LED 3000 K1121 lm22 WDALI
    • 8 730 056 2098 730 056 209Highlinesilver greywall washer 14° / 93°LED 3000 K1281 lm23 W1-10V
    • 8 730 056 2198 730 056 219Highlinesilver greynarrow beam 6°LED 3000 K1487 lm23 W1-10V
    • 8 730 056 2898 730 056 289Highlinesilver greyasymmetrical 35° / 30°LED 3000 K1121 lm22 W1-10V
    • 8 730 045 0098 730 045 009Highlineblackwall washer 14° / 93°LED 4000 K1345 lm23 Won / off
    • 8 730 045 0198 730 045 019Highlineblacknarrow beam 6°LED 4000 K1561 lm23 Won / off
    • 8 730 045 0898 730 045 089Highlineblackasymmetrical 35° / 30°LED 4000 K1177 lm22 Won / off
    • 8 730 045 1098 730 045 109Highlineblackwall washer 14° / 93°LED 4000 K1345 lm23 WDALI
    • 8 730 045 1198 730 045 119Highlineblacknarrow beam 6°LED 4000 K1561 lm23 WDALI
    • 8 730 045 1898 730 045 189Highlineblackasymmetrical 35° / 30°LED 4000 K1177 lm22 WDALI
    • 8 730 045 2098 730 045 209Highlineblackwall washer 14° / 93°LED 4000 K1345 lm23 W1-10V
    • 8 730 045 2198 730 045 219Highlineblacknarrow beam 6°LED 4000 K1561 lm23 W1-10V
    • 8 730 045 2898 730 045 289Highlineblackasymmetrical 35° / 30°LED 4000 K1177 lm22 W1-10V
    • 8 730 046 0098 730 046 009Highlineblackwall washer 14° / 93°LED 3000 K1281 lm23 Won / off
    • 8 730 046 0198 730 046 019Highlineblacknarrow beam 6°LED 3000 K1487 lm23 Won / off
    • 8 730 046 0898 730 046 089Highlineblackasymmetrical 35° / 30°LED 3000 K1121 lm22 Won / off
    • 8 730 046 1098 730 046 109Highlineblackwall washer 14° / 93°LED 3000 K1281 lm23 WDALI
    • 8 730 046 1198 730 046 119Highlineblacknarrow beam 6°LED 3000 K1487 lm23 WDALI
    • 8 730 046 1898 730 046 189Highlineblackasymmetrical 35° / 30°LED 3000 K1121 lm22 WDALI
    • 8 730 046 2098 730 046 209Highlineblackwall washer 14° / 93°LED 3000 K1281 lm23 W1-10V
    • 8 730 046 2198 730 046 219Highlineblacknarrow beam 6°LED 3000 K1487 lm23 W1-10V
    • 8 730 046 2898 730 046 289Highlineblackasymmetrical 35° / 30°LED 3000 K1121 lm22 W1-10V
    • 8 730 065 0098 730 065 009Highlinewhitewall washer 14° / 93°LED 4000 K1345 lm23 Won / off
    • 8 730 065 0198 730 065 019Highlinewhitenarrow beam 6°LED 4000 K1561 lm23 Won / off
    • 8 730 065 0898 730 065 089Highlinewhiteasymmetrical 35° / 30°LED 4000 K1177 lm22 Won / off
    • 8 730 065 1098 730 065 109Highlinewhitewall washer 14° / 93°LED 4000 K1345 lm23 WDALI
    • 8 730 065 1198 730 065 119Highlinewhitenarrow beam 6°LED 4000 K1561 lm23 WDALI
    • 8 730 065 1898 730 065 189Highlinewhiteasymmetrical 35° / 30°LED 4000 K1177 lm22 WDALI
    • 8 730 065 2098 730 065 209Highlinewhitewall washer 14° / 93°LED 4000 K1345 lm23 W1-10V
    • 8 730 065 2198 730 065 219Highlinewhitenarrow beam 6°LED 4000 K1561 lm23 W1-10V
    • 8 730 065 2898 730 065 289Highlinewhiteasymmetrical 35° / 30°LED 4000 K1177 lm22 W1-10V
    • 8 730 066 0098 730 066 009Highlinewhitewall washer 14° / 93°LED 3000 K1281 lm23 Won / off
    • 8 730 066 0198 730 066 019Highlinewhitenarrow beam 6°LED 3000 K1487 lm23 Won / off
    • 8 730 066 0898 730 066 089Highlinewhiteasymmetrical 35° / 30°LED 3000 K1121 lm22 Won / off
    • 8 730 066 1098 730 066 109Highlinewhitewall washer 14° / 93°LED 3000 K1281 lm23 WDALI
    • 8 730 066 1198 730 066 119Highlinewhitenarrow beam 6°LED 3000 K1487 lm23 WDALI
    • 8 730 066 1898 730 066 189Highlinewhiteasymmetrical 35° / 30°LED 3000 K1121 lm22 WDALI
    • 8 730 066 2098 730 066 209Highlinewhitewall washer 14° / 93°LED 3000 K1281 lm23 W1-10V
    • 8 730 066 2198 730 066 219Highlinewhitenarrow beam 6°LED 3000 K1487 lm23 W1-10V
    • 8 730 066 2898 730 066 289Highlinewhiteasymmetrical 35° / 30°LED 3000 K1121 lm22 W1-10V
    • 8 730 155 0098 730 155 009Highlinesilver greywall washer 14° / 93°LED 4000 K1345 lm23 Won / off
    • 8 730 155 0198 730 155 019Highlinesilver greynarrow beam 6°LED 4000 K1561 lm23 Won / off
    • 8 730 155 0898 730 155 089Highlinesilver greyasymmetrical 35° / 30°LED 4000 K1177 lm22 Won / off
    • 8 730 155 1098 730 155 109Highlinesilver greywall washer 14° / 93°LED 4000 K1345 lm23 WDALI
    • 8 730 155 1198 730 155 119Highlinesilver greynarrow beam 6°LED 4000 K1561 lm23 WDALI
    • 8 730 155 1898 730 155 189Highlinesilver greyasymmetrical 35° / 30°LED 4000 K1177 lm22 WDALI
    • 8 730 155 2098 730 155 209Highlinesilver greywall washer 14° / 93°LED 4000 K1345 lm23 W1-10V
    • 8 730 155 2198 730 155 219Highlinesilver greynarrow beam 6°LED 4000 K1561 lm23 W1-10V
    • 8 730 155 2898 730 155 289Highlinesilver greyasymmetrical 35° / 30°LED 4000 K1177 lm22 W1-10V
    • 8 730 156 0098 730 156 009Highlinesilver greywall washer 14° / 93°LED 3000 K1281 lm23 Won / off
    • 8 730 156 0198 730 156 019Highlinesilver greynarrow beam 6°LED 3000 K1487 lm23 Won / off
    • 8 730 156 0898 730 156 089Highlinesilver greyasymmetrical 35° / 30°LED 3000 K1121 lm22 Won / off
    • 8 730 156 1098 730 156 109Highlinesilver greywall washer 14° / 93°LED 3000 K1281 lm23 WDALI
    • 8 730 156 1198 730 156 119Highlinesilver greynarrow beam 6°LED 3000 K1487 lm23 WDALI
    • 8 730 156 1898 730 156 189Highlinesilver greyasymmetrical 35° / 30°LED 3000 K1121 lm22 WDALI
    • 8 730 156 2098 730 156 209Highlinesilver greywall washer 14° / 93°LED 3000 K1281 lm23 W1-10V
    • 8 730 156 2198 730 156 219Highlinesilver greynarrow beam 6°LED 3000 K1487 lm23 W1-10V
    • 8 730 156 2898 730 156 289Highlinesilver greyasymmetrical 35° / 30°LED 3000 K1121 lm22 W1-10V
    • 8 730 145 0098 730 145 009Highlineblackwall washer 14° / 93°LED 4000 K1345 lm23 Won / off
    • 8 730 145 0198 730 145 019Highlineblacknarrow beam 6°LED 4000 K1561 lm23 Won / off
    • 8 730 145 0898 730 145 089Highlineblackasymmetrical 35° / 30°LED 4000 K1177 lm22 Won / off
    • 8 730 145 1098 730 145 109Highlineblackwall washer 14° / 93°LED 4000 K1345 lm23 WDALI
    • 8 730 145 1198 730 145 119Highlineblacknarrow beam 6°LED 4000 K1561 lm23 WDALI
    • 8 730 145 1898 730 145 189Highlineblackasymmetrical 35° / 30°LED 4000 K1177 lm22 WDALI
    • 8 730 145 2098 730 145 209Highlineblackwall washer 14° / 93°LED 4000 K1345 lm23 W1-10V
    • 8 730 145 2198 730 145 219Highlineblacknarrow beam 6°LED 4000 K1561 lm23 W1-10V
    • 8 730 145 2898 730 145 289Highlineblackasymmetrical 35° / 30°LED 4000 K1177 lm22 W1-10V
    • 8 730 146 0098 730 146 009Highlineblackwall washer 14° / 93°LED 3000 K1281 lm23 Won / off
    • 8 730 146 0198 730 146 019Highlineblacknarrow beam 6°LED 3000 K1487 lm23 Won / off
    • 8 730 146 0898 730 146 089Highlineblackasymmetrical 35° / 30°LED 3000 K1121 lm22 Won / off
    • 8 730 146 1098 730 146 109Highlineblackwall washer 14° / 93°LED 3000 K1281 lm23 WDALI
    • 8 730 146 1198 730 146 119Highlineblacknarrow beam 6°LED 3000 K1487 lm23 WDALI
    • 8 730 146 1898 730 146 189Highlineblackasymmetrical 35° / 30°LED 3000 K1121 lm22 WDALI
    • 8 730 146 2098 730 146 209Highlineblackwall washer 14° / 93°LED 3000 K1281 lm23 W1-10V
    • 8 730 146 2198 730 146 219Highlineblacknarrow beam 6°LED 3000 K1487 lm23 W1-10V
    • 8 730 146 2898 730 146 289Highlineblackasymmetrical 35° / 30°LED 3000 K1121 lm22 W1-10V
    • 8 730 165 0098 730 165 009Highlinewhitewall washer 14° / 93°LED 4000 K1345 lm23 Won / off
    • 8 730 165 0198 730 165 019Highlinewhitenarrow beam 6°LED 4000 K1561 lm23 Won / off
    • 8 730 165 0898 730 165 089Highlinewhiteasymmetrical 35° / 30°LED 4000 K1177 lm22 Won / off
    • 8 730 165 1098 730 165 109Highlinewhitewall washer 14° / 93°LED 4000 K1345 lm23 WDALI
    • 8 730 165 1198 730 165 119Highlinewhitenarrow beam 6°LED 4000 K1561 lm23 WDALI
    • 8 730 165 1898 730 165 189Highlinewhiteasymmetrical 35° / 30°LED 4000 K1177 lm22 WDALI
    • 8 730 165 2098 730 165 209Highlinewhitewall washer 14° / 93°LED 4000 K1345 lm23 W1-10V
    • 8 730 165 2198 730 165 219Highlinewhitenarrow beam 6°LED 4000 K1561 lm23 W1-10V
    • 8 730 165 2898 730 165 289Highlinewhiteasymmetrical 35° / 30°LED 4000 K1177 lm22 W1-10V
    • 8 730 166 0098 730 166 009Highlinewhitewall washer 14° / 93°LED 3000 K1281 lm23 Won / off
    • 8 730 166 0198 730 166 019Highlinewhitenarrow beam 6°LED 3000 K1487 lm23 Won / off
    • 8 730 166 0898 730 166 089Highlinewhiteasymmetrical 35° / 30°LED 3000 K1121 lm22 Won / off
    • 8 730 166 1098 730 166 109Highlinewhitewall washer 14° / 93°LED 3000 K1281 lm23 WDALI
    • 8 730 166 1198 730 166 119Highlinewhitenarrow beam 6°LED 3000 K1487 lm23 WDALI
    • 8 730 166 1898 730 166 189Highlinewhiteasymmetrical 35° / 30°LED 3000 K1121 lm22 WDALI
    • 8 730 166 2098 730 166 209Highlinewhitewall washer 14° / 93°LED 3000 K1281 lm23 W1-10V
    • 8 730 166 2198 730 166 219Highlinewhitenarrow beam 6°LED 3000 K1487 lm23 W1-10V
    • 8 730 166 2898 730 166 289Highlinewhiteasymmetrical 35° / 30°LED 3000 K1121 lm22 W1-10V
    • 8 730 755 0098 730 755 009Highlinesilver greywall washer 14° / 93°LED 4000 K1345 lm23 Won / off
    • 8 730 755 1098 730 755 109Highlinesilver greywall washer 14° / 93°LED 4000 K1345 lm23 WDALI
    • 8 730 755 2098 730 755 209Highlinesilver greywall washer 14° / 93°LED 4000 K1345 lm23 W1-10V
    • 8 730 756 0098 730 756 009Highlinesilver greywall washer 14° / 93°LED 3000 K1281 lm23 Won / off
    • 8 730 756 1098 730 756 109Highlinesilver greywall washer 14° / 93°LED 3000 K1281 lm23 WDALI
    • 8 730 756 2098 730 756 209Highlinesilver greywall washer 14° / 93°LED 3000 K1281 lm23 W1-10V
    • 8 730 745 0098 730 745 009Highlineblackwall washer 14° / 93°LED 4000 K1345 lm23 Won / off
    • 8 730 745 1098 730 745 109Highlineblackwall washer 14° / 93°LED 4000 K1345 lm23 WDALI
    • 8 730 745 2098 730 745 209Highlineblackwall washer 14° / 93°LED 4000 K1345 lm23 W1-10V
    • 8 730 746 0098 730 746 009Highlineblackwall washer 14° / 93°LED 3000 K1281 lm23 Won / off
    • 8 730 746 1098 730 746 109Highlineblackwall washer 14° / 93°LED 3000 K1281 lm23 WDALI
    • 8 730 746 2098 730 746 209Highlineblackwall washer 14° / 93°LED 3000 K1281 lm23 W1-10V
    • 8 730 765 0098 730 765 009Highlinewhitewall washer 14° / 93°LED 4000 K1345 lm23 Won / off
    • 8 730 765 1098 730 765 109Highlinewhitewall washer 14° / 93°LED 4000 K1345 lm23 WDALI
    • 8 730 765 2098 730 765 209Highlinewhitewall washer 14° / 93°LED 4000 K1345 lm23 W1-10V
    • 8 730 766 0098 730 766 009Highlinewhitewall washer 14° / 93°LED 3000 K1281 lm23 Won / off
    • 8 730 766 1098 730 766 109Highlinewhitewall washer 14° / 93°LED 3000 K1281 lm23 WDALI
    • 8 730 766 2098 730 766 209Highlinewhitewall washer 14° / 93°LED 3000 K1281 lm23 W1-10V
