8 204 045 039
Monoflood 4
Monoflood 4
Monoflood 1
Monoflood 2
Monoflood 3
Monoflood 4
Monoflood 2
Monoflood 3
Monoflood 4
Housing colour
Fixation
Colour temperature
Light distribution
Linear, horizontal
Narrow beam
Linear, vertical
Linear, horizontal
Medium wide beam
Axially symmetrical wide beam
Axially symmetrical, narrow beam
Linear, rotatable
Asymmetrical beam
Extreme narrow beam
Linear, vertical
Linear, horizontal
Medium wide beam
Axially symmetrical wide beam
Axially symmetrical, narrow beam
Linear, rotatable
Asymmetrical beam
Extreme narrow beam
Specification
- Colour
- black
- Fixation
- with mounting bracket
- Light distribution
- linear, horizontal
- Beam angle (FWHM)
- 9° / 40°
- Light source
- LED 4000 K
- Luminous flux
- 5506 lm
- Power
- 98 W
- Efficiency
- 56 lm/W
- Control
- on / off
- Color Rendering Index cri
- CRI > 80 > 80
- Colour tolerance
- max 3 SDCM
- Service life
- L: 90, B:10
Download
Add accessories to your data sheet with a click.
129 0 736 940 | black
Earth spike stainless steel, for use in landscaped areas
129 0 790 940 | black
singe pole mount adapter aluminium, for poles Ø 60 mm
129 0 791 940 | black
double pole mount adapter aluminium, for poles Ø 60 mm
129 0 792 940 | black
singe pole mount adapter aluminium, for poles Ø 76 mm
129 0 793 940 | black
double pole mount adapter aluminium, for poles Ø 76 mm
129 0 850 940 | black
singe pole mount adapter aluminium, for poles Ø 60-80 mm
122 0 414 | black
Honeycomb louvre internal (factory fitted), to avoid glare
122 0 410
Prismatic glass for diffused light distribution, internal (factory fitted)
122 0 404 940 | black
Cowl stainless steel, to avoid glare from 3 directions, for mounting in front of floodlight
