  • Nightspot A
    Design: Roy Fleetwood

    ×

    8 965 246 049

    Nightspot A

    Housing colour

    silver grey
    black
    white

    Fixation

    with mounting base
    with earthspike
    with wall arm

    Colour temperature

    4000 K
    3000 K

    Light distribution

    Specification
    Colour
    black
    Fixation
    with earthspike
    Light distribution
    medium wide beam
    Beam angle (FWHM)
    22°
    Light source
    LED 3000 K
    Luminous flux
    439 lm
    Power
    8 W
    Efficiency
    55 lm/W
    Control
    on / off
    Color Rendering Index cri
    typ 80 typ 80
    Colour tolerance
    max 2 SDCM
    Service life
    L: 90, B:10
    Download
    Add accessories to your data sheet with a click.

    129 0 399 940 | black

    Cowl stainless steel, to reduce lateral glare, for retro fitting, not in combination with other accessories
    Download data sheet

    Nightspot A is a series of compact floodlights for miniature metal halide lamps, low voltage reflector lamps or with LEDs. The range is very versatile: there are versions with integral or remote control gear, if re- quired with wall arm or with integral earth spike. Various light distributions are available which can be adapted to suit individual requirements with the help of internal accessories.

    Preselection
    Light source
    Fixation
    Colour
    Light distribution
    Colour temperature
    Control

    72 Products
    •   Part number Description Colour Light distribution Light source Luminous flux Power
    • 8 965 155 0198 965 155 019Nightspot Asilver greynarrow beam 6°LED 4000 K541 lm6 Won / off
    • 8 965 155 0298 965 155 029Nightspot Asilver greylinear vertical 51° / 8°LED 4000 K467 lm6 Won / off
    • 8 965 155 0498 965 155 049Nightspot Asilver greymedium wide beam 22°LED 4000 K526 lm6 Won / off
    • 8 965 155 0598 965 155 059Nightspot Asilver greywide beam 45°LED 4000 K478 lm6 Won / off
    • 8 965 156 0198 965 156 019Nightspot Asilver greynarrow beam 6°LED 3000 K506 lm6 Won / off
    • 8 965 156 0298 965 156 029Nightspot Asilver greylinear vertical 51° / 8°LED 3000 K445 lm6 Won / off
    • 8 965 156 0498 965 156 049Nightspot Asilver greymedium wide beam 22°LED 3000 K501 lm6 Won / off
    • 8 965 156 0598 965 156 059Nightspot Asilver greywide beam 45°LED 3000 K455 lm6 Won / off
    • 8 965 145 0198 965 145 019Nightspot Ablacknarrow beam 6°LED 4000 K541 lm6 Won / off
    • 8 965 145 0298 965 145 029Nightspot Ablacklinear vertical 51° / 8°LED 4000 K467 lm6 Won / off
    • 8 965 145 0498 965 145 049Nightspot Ablackmedium wide beam 22°LED 4000 K526 lm6 Won / off
    • 8 965 145 0598 965 145 059Nightspot Ablackwide beam 45°LED 4000 K478 lm6 Won / off
    • 8 965 146 0198 965 146 019Nightspot Ablacknarrow beam 6°LED 3000 K506 lm6 Won / off
    • 8 965 146 0298 965 146 029Nightspot Ablacklinear vertical 51° / 8°LED 3000 K445 lm6 Won / off
    • 8 965 146 0498 965 146 049Nightspot Ablackmedium wide beam 22°LED 3000 K501 lm6 Won / off
    • 8 965 146 0598 965 146 059Nightspot Ablackwide beam 45°LED 3000 K455 lm6 Won / off
    • 8 965 165 0198 965 165 019Nightspot Awhitenarrow beam 6°LED 4000 K541 lm6 Won / off
    • 8 965 165 0298 965 165 029Nightspot Awhitelinear vertical 51° / 8°LED 4000 K467 lm6 Won / off
    • 8 965 165 0498 965 165 049Nightspot Awhitemedium wide beam 22°LED 4000 K526 lm6 Won / off
    • 8 965 165 0598 965 165 059Nightspot Awhitewide beam 45°LED 4000 K478 lm6 Won / off
    • 8 965 166 0198 965 166 019Nightspot Awhitenarrow beam 6°LED 3000 K506 lm6 Won / off
    • 8 965 166 0298 965 166 029Nightspot Awhitelinear vertical 51° / 8°LED 3000 K445 lm6 Won / off
    • 8 965 166 0498 965 166 049Nightspot Awhitemedium wide beam 22°LED 3000 K501 lm6 Won / off
    • 8 965 166 0598 965 166 059Nightspot Awhitewide beam 45°LED 3000 K455 lm6 Won / off
    • 8 965 255 0198 965 255 019Nightspot Asilver greynarrow beam 6°LED 4000 K541 lm6 Won / off
    • 8 965 255 0298 965 255 029Nightspot Asilver greylinear vertical 51° / 8°LED 4000 K467 lm6 Won / off
    • 8 965 255 0498 965 255 049Nightspot Asilver greymedium wide beam 22°LED 4000 K526 lm6 Won / off
    • 8 965 255 0598 965 255 059Nightspot Asilver greywide beam 45°LED 4000 K478 lm6 Won / off
    • 8 965 256 0198 965 256 019Nightspot Asilver greynarrow beam 6°LED 3000 K506 lm6 Won / off
    • 8 965 256 0298 965 256 029Nightspot Asilver greylinear vertical 51° / 8°LED 3000 K446 lm6 Won / off
    • 8 965 256 0498 965 256 049Nightspot Asilver greymedium wide beam 22°LED 3000 K439 lm8 Won / off
    • 8 965 256 0598 965 256 059Nightspot Asilver greywide beam 45°LED 3000 K455 lm6 Won / off
    • 8 965 245 0198 965 245 019Nightspot Ablacknarrow beam 6°LED 4000 K541 lm6 Won / off
    • 8 965 245 0298 965 245 029Nightspot Ablacklinear vertical 51° / 8°LED 4000 K467 lm6 Won / off
    • 8 965 245 0498 965 245 049Nightspot Ablackmedium wide beam 22°LED 4000 K526 lm6 Won / off
    • 8 965 245 0598 965 245 059Nightspot Ablackwide beam 45°LED 4000 K478 lm6 Won / off
    • 8 965 246 0198 965 246 019Nightspot Ablacknarrow beam 6°LED 3000 K506 lm6 Won / off
    • 8 965 246 0298 965 246 029Nightspot Ablacklinear vertical 51° / 8°LED 3000 K446 lm6 Won / off
    • 8 965 246 0498 965 246 049Nightspot Ablackmedium wide beam 22°LED 3000 K439 lm8 Won / off
    • 8 965 246 0598 965 246 059Nightspot Ablackwide beam 45°LED 3000 K455 lm6 Won / off
    • 8 965 265 0198 965 265 019Nightspot Awhitenarrow beam 6°LED 4000 K541 lm6 Won / off
    • 8 965 265 0298 965 265 029Nightspot Awhitelinear vertical 51° / 8°LED 4000 K467 lm6 Won / off
    • 8 965 265 0498 965 265 049Nightspot Awhitemedium wide beam 22°LED 4000 K526 lm6 Won / off
    • 8 965 265 0598 965 265 059Nightspot Awhitewide beam 45°LED 4000 K478 lm6 Won / off
    • 8 965 266 0198 965 266 019Nightspot Awhitenarrow beam 6°LED 3000 K506 lm6 Won / off
    • 8 965 266 0298 965 266 029Nightspot Awhitelinear vertical 51° / 8°LED 3000 K446 lm6 Won / off
    • 8 965 266 0498 965 266 049Nightspot Awhitemedium wide beam 22°LED 3000 K439 lm8 Won / off
    • 8 965 266 0598 965 266 059Nightspot Awhitewide beam 45°LED 3000 K455 lm6 Won / off
    • 8 965 655 0198 965 655 019Nightspot Asilver greynarrow beam 6°LED 4000 K541 lm6 Won / off
    • 8 965 655 0298 965 655 029Nightspot Asilver greylinear vertical 51° / 8°LED 4000 K467 lm6 Won / off
    • 8 965 655 0498 965 655 049Nightspot Asilver greymedium wide beam 22°LED 4000 K526 lm6 Won / off
    • 8 965 655 0598 965 655 059Nightspot Asilver greywide beam 45°LED 4000 K478 lm6 Won / off
    • 8 965 656 0198 965 656 019Nightspot Asilver greynarrow beam 6°LED 3000 K506 lm6 Won / off
    • 8 965 656 0298 965 656 029Nightspot Asilver greylinear vertical 51° / 8°LED 3000 K446 lm6 Won / off
    • 8 965 656 0498 965 656 049Nightspot Asilver greymedium wide beam 22°LED 3000 K501 lm6 Won / off
    • 8 965 656 0598 965 656 059Nightspot Asilver greywide beam 45°LED 3000 K455 lm6 Won / off
    • 8 965 645 0198 965 645 019Nightspot Ablacknarrow beam 6°LED 4000 K541 lm6 Won / off
    • 8 965 645 0298 965 645 029Nightspot Ablacklinear vertical 51° / 8°LED 4000 K467 lm6 Won / off
    • 8 965 645 0498 965 645 049Nightspot Ablackmedium wide beam 22°LED 4000 K526 lm6 Won / off
    • 8 965 645 0598 965 645 059Nightspot Ablackwide beam 45°LED 4000 K478 lm6 Won / off
    • 8 965 646 0198 965 646 019Nightspot Ablacknarrow beam 6°LED 3000 K506 lm6 Won / off
    • 8 965 646 0298 965 646 029Nightspot Ablacklinear vertical 51° / 8°LED 3000 K446 lm6 Won / off
    • 8 965 646 0498 965 646 049Nightspot Ablackmedium wide beam 22°LED 3000 K501 lm6 Won / off
    • 8 965 646 0598 965 646 059Nightspot Ablackwide beam 45°LED 3000 K455 lm6 Won / off
    • 8 965 665 0198 965 665 019Nightspot Awhitenarrow beam 6°LED 4000 K541 lm6 Won / off
    • 8 965 665 0298 965 665 029Nightspot Awhitelinear vertical 51° / 8°LED 4000 K467 lm6 Won / off
    • 8 965 665 0498 965 665 049Nightspot Awhitemedium wide beam 22°LED 4000 K526 lm6 Won / off
    • 8 965 665 0598 965 665 059Nightspot Awhitewide beam 45°LED 4000 K478 lm6 Won / off
    • 8 965 666 0198 965 666 019Nightspot Awhitenarrow beam 6°LED 3000 K506 lm6 Won / off
    • 8 965 666 0298 965 666 029Nightspot Awhitelinear vertical 51° / 8°LED 3000 K446 lm6 Won / off
    • 8 965 666 0498 965 666 049Nightspot Awhitemedium wide beam 22°LED 3000 K501 lm6 Won / off
    • 8 965 666 0598 965 666 059Nightspot Awhitewide beam 45°LED 3000 K455 lm6 Won / off
